Apex ABS 368A

Apex ABS 368A is a rear crankshaft seal kit, also listed as a rear main seal set. It seals the crankshaft exit at the rear of the engine, on the flywheel or converter side.

Application / fitment

ABS368A is cataloged as a rear crankshaft seal kit for selected GM Northstar 4.0 / 244 and 4.6 / 281 engines. Catalog data lists rear position, a 12 mm rear main seal, PTFE construction and a 2nd design condition for some 1996 Cadillac DeVille 4.6 / 281 applications.

• part type: rear crankshaft seal kit / rear main seal set
• mounting location: rear crankshaft end
• seal width: 12 mm
• seal material: PTFE / polytetrafluoroethylene
• design: 1-piece rear main seal
• function: engine oil sealing at the crankshaft rear exit
• selected catalog applications: Cadillac DeVille 4.6 / 281 V8 1996-2005, 1996 depending on 2nd design
• catalog application family: Buick, Cadillac, Oldsmobile and Pontiac GM Northstar 4.0 / 244 and 4.6 / 281
• selection basis: ABS368A number, 12 mm width, rear housing style, crankshaft flange, seal lip direction
• installation check: crankshaft sealing surface and crankcase ventilation condition
• do not select by engine family alone

Before installation, inspect the crankshaft sealing surface for a groove and make sure the seal lip is not folded during pressing. A PTFE seal needs a clean, dry running surface and square installation. A blocked crankcase ventilation system can force oil past a new rear seal, so check ventilation before final diagnosis.

Technical information

• part type: rear main seal kit
• operating area: crankshaft and rear engine housing
• function: crankshaft oil sealing
• width: 12 mm
• material: PTFE
• position: rear
• application note: 2nd design on some 1996 Cadillac DeVille listings
• verify by: ABS368A number, 12 mm width, rear location, housing shape, removed part dimensions
• sale unit: 1 kit
