Edelbrock 5822

Edelbrock 5822 is a single valve spring set for selected Ford cast iron cylinder heads and Edelbrock Performer camshaft combinations. It is used during valvetrain service or upgrade when the spring parameters must match the camshaft and cylinder head requirements.

Application / fitment

Edelbrock references 5822 for selected Ford 289/302, 5.0 and 5.8 applications, especially Performer combinations and OE heads without valve rotators. For valve rotator applications, Edelbrock lists a different spring number, 5922.

• part type: valve spring
• position: intake and exhaust valves, depending on cylinder head configuration
• selected applications: Ford 289/302 1965-1995; 5.0 EFI 1986-1995 Mustang; selected 5.0 and 5.8 truck applications 1987-1995; Performer combinations requiring Edelbrock 5822
• condition: OE cast iron heads without valve rotators; rotator setups use a different catalog number

Before installation, check installed height, retainers, locks, valve stem seals and actual cam lift to maintain adequate clearance before coil bind.

Technical information

• part type: single valve spring set
• installed height: 1.700" / 43.18 mm; the 2122 camshaft instruction lists 1.660" / 42.16 mm for 5822 in that combination
• seat load / installed pressure: 90 lb
• open load / open pressure: 210 lb @ 0.400" / 10.16 mm lift
• OD: 1.354" / 34.39 mm
• ID: 1.010" / 25.65 mm
• coil bind: 1.200" / 30.48 mm
• spring type: single, no damper, non-rotator
• recommended retainers: Edelbrock 9724 where required by the build
• sale unit: set
